| Capacity |
6, 60 kg |
| Accuracy Class |
C3 |
| Minimum Load |
0 kg |
| Maximum Number of Partitions (nLC) |
3000 |
| Minimum Measurement Range |
10.000 (Y=Emax / Vmin) |
| Total Error |
±0.02 %FS |
| Output Gain (FS) |
2.00 ± 0.01 mV/V |
| Zero Balance |
± 1 %FS |
| Input Resistance |
380 Ω ± 10 Ω |
| Output Resistance |
350 Ω ± 2 Ω |
| Insulation Resistance |
≤ 5000 MΩ (100VDC) |
| Compensated Operating Temperature |
-10 ~ +40 °C |
| Operating Temperature Range |
-30 ~ +70 °C |
| Recommended Excitation Voltage |
10 VDC |
| Maximum Excitation Voltage (Umax) |
15 VDC |
| Overload Capacity |
120 % FS |
| Fracture Load |
200 % FS |
| Protection Class (EN60529) |
IP 68 |
| Load Cell Material |
Stainless Steel |
| Cable |
4x022mm² – 3 M. |
